Design, Production and Impact Test of Multi-Axle Heavy Commercial Vehicle Cab

Main Article Content

Aziz Başdemir
Yiğit Vatansever
Şenol Şentürk
Emre Tekin

Abstract

The main and most complex superstructure module of heavy-duty and heavy commercial vehicles is the driver-passenger cabin. While cabin design and production; It must be safe, light, rigid, ergonomic, modular, suitable for lean production, user-friendly and serviceable. But the most important of these criteria is the life safety of the crew in the cab. In this context, the cabin strength must be at a very high level. To determine the cabin strength, it is subjected to the R29 - Cabin strength test within the ECE regulations. Thanks to this test, it is possible to see the skeletal strength and behavior of the cabin in the event of an accident or collision. According to this test, the life safety of the crew inside the cabin must be prioritized, and the necessary designs and production must be carried out to ensure that the cabin suffers as little damage as possible in the event of an accident. In this way, it is aimed to maximize the security (safe area) inside the cabin by providing cabin rigidity. This scope of work; The objectives of lighter weight, shorter and easier production, assembly and disassembly, lower production costs, less labor and equipment or consumable expenses have been achieved. Additionally, in this study, the seat configuration in the cabin was increased from 1+4 to 1+5 and a crash test was performed by including another door option.

Downloads

Download data is not yet available.

Article Details

How to Cite
Başdemir, A., Vatansever, Y., Şentürk, Şenol, & Tekin, E. (2023). Design, Production and Impact Test of Multi-Axle Heavy Commercial Vehicle Cab. The European Journal of Research and Development, 3(4), 357–368. https://doi.org/10.56038/ejrnd.v3i4.413
Section
Articles

References

Başdemir, A., Kaynak R., & Tekin E. (2022). Structural Analysis of Different Types of Chassis Designs for a Multi-Axle Heavy Commercial Vehicle. The European Journal of Research and Development,2(4), 338-355. DOI: https://doi.org/10.56038/ejrnd.v2i4.210

Regulation No 29 of the Economic Commission for Europe of the United Nations (UN/ECE) — Uniform provisions concerning the approval of vehicles with regard to the protection of the occupants of the cab of a commercial vehicle, 2011. ECE R 29.03 Supp.05.

Capar, G., Kuralay, N.S., & Karaoglan, M.U. (2020). Özel Maksatlı Bir Ağır Hizmet Aracı için Kabin Darbe Test Düzeneğinin Tasarımı/Uygulanması ve Kabin Dayanımının Regülasyona Uygunluğunun İncelenmesi. DEUFMD, 22(65), 611-618. DOI: https://doi.org/10.21205/deufmd.2020226526

Pasha, H., Madhuchandra, K.S., Rajesh, P., & Basavaraja, J. (2018). Reinforcement Design and Crash Analysis of Medium Duty Trucks for Rollover Crash Accidents International Journal of Engineering Research in Mechanical and Civil Engineering, 3(5).

Cengiz, A. (2007). Kompozit çubukların enerji sönümleyici özelliklerinin incelenmesi. Kocaeli Üniversitesi, Fen Bilimleri Enstitüsü, Doktora Tezi.

Büyük, M., Atahan, A.O., Kurucuoğlu, K. (2018). Impact Performance Evaluation of a Crash Cushion Design Using Finite Element Simulation and Full-Scale Crash Testing. İstanbul Teknik Üniversitesi, İstanbul. DOI: https://doi.org/10.3390/safety4040048

Yaşar, F. (2011). N3 sınıfı ağır ticari bir aracın ECE R29 standartına uygun önden çarpma analizi ve iyileştirme çalışmaları. İstanbul Teknik Üniversitesi. Fen Bilimleri Enstitüsü, Yüksek Lisans Tezi, İstanbul.

NFPA-414, (2020). Standard for Aircraft Rescue and FireFighting Vehicles.
